• ASRock Super Alloy
  - Premium Alloy Choke (Reduces 70% core loss compared to iron powder choke)
  - NexFET™ MOSFET
  - Sapphire Black PCB
  ASRock Full Spike Protection
  ASRock Cloud
  ASRock APP Shop
• - Supports 5th Generation Intel^® Core™ i7 / i5 / i3 / Pentium^® / Celeron^® Processors (Socket 1150)
  - Supports New 4th and 4th Generation Intel^® Xeon^® / Core™ i7 / i5 / i3 / Pentium^® / Celeron^® Processors (Socket 1150)
  - Digi Power design
  - 4 Power Phase design
  - Supports Intel^® Turbo Boost 2.0 Technology
• - Intel^® H97
  - Supports Intel^® Small Business Advantage 2.0
• - Dual Channel DDR3/DDR3L Memory Technology
  - 4 x DDR3/DDR3L DIMM Slots
  - Supports DDR3/DDR3L 1600/1333/1066 non-ECC, un-buffered memory
  - Max. capacity of system memory: 32GB*
  - Supports Intel^® Extreme Memory Profile (XMP) 1.3 / 1.2


  *Az operációs rendszer korlátai miatt a tényleges memóriaméret kevesebb lehet 4 GB-nál, mert a rendszer 32 bites Windows^® operációs rendszer alatt saját használatra fenntartja egy részét.. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.
• - 128Mb AMI UEFI Legal BIOS with multilingual GUI support
  - ACPI 1.1 Compliant wake up events
  - SMBIOS 2.3.1 support
  - CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage multi-adjustment
• - Supports Intel^® HD Graphics Built-in Visuals : Intel^® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel^® InTru™ 3D, Intel^® Clear Video HD Technology, Intel^® Insider™, Intel^® HD Graphics 4400/4600
  - Pixel Shader 5.0, DirectX 11.1
  - Max. shared memory 512MB*
  - Three graphics output options: D-Sub, DVI-D and HDMI
  - Supports Triple Monitor
  - Supports HDMI with max. resolution up to 1920x1200 @ 60Hz
  - Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
  - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
  - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
  - Supports HDCP with DVI-D and HDMI Ports
  - Supports Full HD 1080p Blu-ray (BD) playback with DVI-D and HDMI Ports


  *A megosztott memória maximális mérete operációs rendszerenként eltérő.
  **Az Intel^® HD Graphics Built-in Visuals és VGA támogatása csak beépített GPU-val rendelkező processzorok esetében lehetséges.
  ***Due to chipset limitation, the Blu-ray playback of Intel^® HD Graphics is only supported under Windows^® 8 / 8 64-bit / 7 / 7 64-bit.
  ****Intel^® InTru™ 3D is only supported under Windows^® 8 / 8 64-bit / 7 / 7 64-bit.
• - 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)
  - Premium Blu-ray Audio support
  - Supports Surge Protection (ASRock Full Spike Protection)
  - ELNA Audio Caps
• - Gigabit LAN 10/100/1000 Mb/s
  - Giga PHY Intel^® I218V
  - Supports Intel^® Remote Wake Technology
  - Supports Wake-On-LAN
  - Supports Lightning/ESD Protection (ASRock Full Spike Protection)
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE
• - 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
  - 1 x PCI Express 2.0 x16 Slot (PCIE2: x4 mode)
  - 2 x PCI Slots
  - Supports AMD Quad CrossFireX™ and CrossFireX™
• - 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel^® Rapid Storage Technology 13 and Intel^® Smart Response Technology), NCQ, AHCI and Hot Plug
• - 1 x Print Port Header
  - 1 x COM Port Header
  - 1 x Chassis Intrusion Header
  - 1 x TPM Header
  - 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
  - 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin)
  - 1 x Power Fan Connector (3-pin)
  - 1 x 24 pin ATX Power Connector
  - 1 x 8 pin 12V Power Connector
  - 1 x Front Panel Audio Connector
  - 1 x Thunderbolt™ AIC Connector*
  - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
  - 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection (ASRock Full Spike Protection))


  *Frissítsen e legújabb BIOS-ra a Thunderbolt™ technológia támogatásához.
• - 1 x PS/2 Mouse/Keyboard Port
  - 1 x D-Sub Port
  - 1 x DVI-D Port
  - 1 x HDMI Port
  - 1 x Optical SPDIF Out Port
  - 2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))
  - 4 x USB 3.1 Gen1 Ports (Supports ESD Protection (ASRock Full Spike Protection))
  - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
• Software
  - ASRock A-Tuning
  - ASRock Disk Health Report
  - ASRock USB Key
  - ASRock System Browser
  - ASRock APP Charger
  - ASRock XFast LAN
  - ASRock XFast RAM
  - ASRock Restart to UEFI
  UEFI
  - ASRock Full HD UEFI
  - ASRock My Favorites in UEFI
  - ASRock UEFI Guide
  - ASRock Instant Flash
  - ASRock Internet Flash
  - ASRock Crashless BIOS
  - ASRock OMG (Online Management Guard)
  - ASRock UEFI Tech Service
  - ASRock Dehumidifier
  - ASRock Easy RAID Installer
  - ASRock Easy Driver Installer
• - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar, Start8 (30 days trial), Orbweb.ME Professional (Win 8.1)
• - Quick Installation Guide, Support CD, I/O Shield
  - 2 x SATA Data Cables
• - CPU, Chassis temperature sensing
  - CPU, Chassis, Power Fan Tachometer
  - CPU, Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature)
  - CPU, Chassis Fan multi-speed control
  - CASE OPEN detection
  - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
• - Micro ATX Form Factor
  - Solid Capacitor design
  - High Density Glass Fabric PCB
• - Microsoft^® Windows^® 10 64-bit / 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit
• - FCC, CE
  - ErP/EuP ready (ErP/EuP ready power supply is required)
